SQUARE WAVE GENERATOR KIT
- $4.35
- Brand: Aretronics
- Availability: 7 In Stock
- SKU: KT-143
• Main Chip: NE555• Input current: >=100MA• Input Voltage: 5V-15VDC• Output amplitude: 4.2V V-PP to 11.4V V-PP• Maximum output current: >=15MA• The output frequency range is selectable: LF file: 1Hz...
Tags: Electronic kits
• Main Chip: NE555
• Input current: >=100MA
• Input Voltage: 5V-15VDC
• Output amplitude: 4.2V V-PP to 11.4V V-PP
• Maximum output current: >=15MA
• The output frequency range is selectable: LF file: 1Hz ~ 50Hz, IF file: 50Hz ~ 1kHz, High-frequency file: 1KHz ~ 10kHz, HF file: 10kHz ~ 200kHz
• The output frequency is adjustable:
1) Period T = 0.7 (RA +2 RB) C
2) RA, RB is 0-10K adjustable
3) Low profile when C = 0.001UF
4) IF stalls C = 0.1UF
5) High-frequency file C = 1UF
6) HF stalls C = 100UF
Spec sheet available in PDF format
